help with mechatron part number for sirocco

[kninio]

Hello any one have access to online etka to give me the right part number for mechatron of vw sirroco , here is the vin number of the car , any help would be appreciated. here is the vin WVWZZZ13ZAV413128

[UrS4boy]

I might have a friend who can help but I have no idea what a "mechatron" is. Enlighten me (please).

And what year is the car? Looks like 1997 which is after the Mark II Scirrocos ended production.

A searched "Mechatron" and came up with this (which I presume is not what you want):

[saltinot]

Sorry to hear you are still having trouble? I thought we had it fixed?

[Monkeymagic]

I assume it is a modern rocco with dsg box

[UrS4boy]

I assume it is a modern rocco with dsg box

That would make some sense. The "A" in WVWZZZ13ZAV413128 = 2010 model year. I was at the Paris Auto Salon in Sept. 2010 and I think that the new Scirroco was just out.

[kninio]

sorry for late delay , its another car last one was golf 5 gti and its donne but this one is sirroco 2010 , dsg mechatron is problematic , mechatron is like the valve body of automatic car but the ecu is built on it

[kninio]

Sorry to hear you are still having trouble? I thought we had it fixed?

last one is fixed, i got the mechatron from ecs tuning and fit it but found out that the dsg syncronizing hubs was damaged and took time to get it fixed but on the end its donne

[kninio]

I assume it is a modern rocco with dsg box

yep its the modern one 2010 , i dont know if it cames to us markets but we have them here in lebanon

[Monkeymagic]

I thought vw did a 10 year 100k warranty on dsg box. Cant you throw it back at them?

[kninio]

no we cant , and they will charge for it 4500$ or 3300$ if u buy it and fit by yourself , we have the most bad and thief vw and audi dealer.

[saltinot]

What's the engine and gearbox codes?

[kninio]

i know none of them just that its 2010 and 2.0t

[saltinot]

OK, here's all the info for a 2010 Scirocco. I parsed this from an up-to-date version of the Elektronische TeileKAtalog. You can figure it out once you get your engine and gearbox codes.

You should be able to see the current part number of the mechatronic with your favorite diagnostic software by logging into the controller. hint, hint.

This is the second one now. What are you guys doing to these poor things over there? Let me know if you need any more help.

Tom

_______________________________

mechatronic with software for 6-speed dual clutch gearbox - DQ250 - petr. engine

02E 325 025 AM mechatronic with software
* order only with color code *

06/08 ZC0 mechatronic with software KPV,LQZ+CAWB
06/08 ZC4 mechatronic with software KPV,LQZ+CCZB
06/08 ZGB mechatronic with software LTL,MMA,MSY+CAWB
06/08 ZPY mechatronic with software NLR+CAWB
06/08 ZW8 mechatronic with software LTL,MMA,MSY,NJL,NLR,PBH+CCZB
06/08 ZWD mechatronic with software LPY,MMD,MTC,NJP,NLT,PBL+CDLC,CDLA
05/13 ZYE mechatronic with software PQA
05/13 ZZ1 mechatronic with software PQD

__________________________________

mechatronic with software for 7-speed dual clutch gearbox - DQ200 - petrol eng.+CTHD,CTKA

0AM 325 025 H mechatronic with software
* order only with color code *

08/12-11/12 Z53 mechatronic with software NTP+CTKA
11/12 Z65 mechatronic with software PMH+CTKA
>05/13 ZBH mechatronic with software PKM+CTKA
08/12-11/12 Z52 mechatronic with software NTP+CTHD
11/12 Z64 mechatronic with software PMH+CTHD
>05/13 ZBG mechatronic with software PKM+CTHD
08/12-11/12 Z5H mechatronic with software NTX
11/12 Z6M mechatronic with software PMQ
05/13 ZC0 mechatronic with software PKU

__________________________________

mechatronic with software for 7-speed dual clutch gearbox - DQ200 - petrol eng.+CAVD,CNWA

0AM 325 025 D mechatronic with software
* order only with color code *

06/08-05/10 ZCZ mechatronic with software MYQ
05/10-11/10 Z4U mechatronic with software MLD
05/10-11/10 Z9V mechatronic with software MYR
05/10-11/10 Z5B mechatronic with software MSL
11/10-05/11 Z85 mechatronic with software MPK+PR-0GV,7MG
11/10-05/11 Z86 mechatronic with software MPK+PR-7MH
11/10-05/11 Z83 mechatronic with software MUV
06/08-05/10 ZCM mechatronic with software LKP,LPL,LWW,MGM

0AM 325 025 H mechatronic with software
* order only with color code *

05/11-11/12 Z52 mechatronic with software NAU,NQA,NTP+PR-0GV,7MG
11/12 Z64 mechatronic with software PMH+PR-0GV,7MG
>05/13 ZBG mechatronic with software PKM+PR-0GV,7MG
11/12 Z65 mechatronic with software PMH+PR-7MD,7MH
05/13 ZBH mechatronic with software PKM+PR-7MD,7MH
05/11-11/12 Z5H mechatronic with software NQJ,NTX,NAZ
11/12 Z6M mechatronic with software PMQ
05/13 Z91 mechatronic with software PKU
__________________________________

mechatronic with software for 7-speed dual clutch gearbox - DQ200 - petrol eng.+CMSB

0AM 325 025 H mechatronic with software
* order only with color code *

04/11-11/12Z5J mechatronic with software NBA,NQK,NTZ
11/12-05/13Z6N mechatronic with software PMS
05/13 ZC2 mechatronic with software PKW

[kninio]

thank you

[kninio]

they just fail often do to hot atmospher i think bord circuit got overheated and guides to trouble , some times it doesnt shift properly and it ends up with damaged syncronizing hubs which is not available from audi as a replacment part only complete gearbox
