  • Extra oil temp .. ABY engine

    Hi guys .. i want to put a oiltemp on the engine .. the thing is i hove no more places to use .. i wonder if there is picture where you can see all the points that are oil and you can use.?

    Thanks

  • #2
    Do you want sump temperature, temperature after oil pump, or....?

    Comment


    • #3
      i think the sump temperature would be good .. could change the sump nut to one with 1,8 npt outlet in centre.
      What is the original thread on the sump ?

      Comment


      • #4
        Originally posted by S2_avant 19930325 View Post
        i think the sump temperature would be good .. could change the sump nut to one with 1,8 npt outlet in centre.
        What is the original thread on the sump ?
        Here is what I did when I wanted a oil temp gauge in my maxxecu/Audi urs4.
        Bought a new oil sump plug from autoexperten, drilled and tapped the plug with the right threads for the temp sensor.
        https://www.s2forum.com/forum/member...project/page15

        Comment


        • #5
          Exactly what i did .. i just hope the thread is M26

          Comment


          • #6
            Exactly what i did .. hope the thread is M26

            Comment


            • #7
              Some easy 1 min search:
              http://www.maxxtuning.se/produkter/m...ten-eller-olja
              http://www.autokatalogen.se/afw/malm...odeIdNo=570492

              Comment


              • #8
                Easy search

                Sump plug all 5Cyl Audi threads: M 26 x 1,50
                Bosch M12 CLT temp sensor: M12x1.5mm

                Comment


                • #9
                  Nice work. What type of gauge are you guys connecting this to? Might do something similar.
                  Nothelle S2 Avant in restoration
                  Wr Ur Quattro (also in restoration)

                  Comment


                  • #10
                    I used 1/8 NPT fitting , dont want to use M fitting , dont want the extra spacer.

                    When i try to upload a picture from photo album ... i get this ... SyntaxError: Unexpected token < in JSON at position 0”

                    Why

                    Comment


                    • #11
                      Connected to MaxxEcu for me, got all inputs/values on a tablet
                      https://www1.garaget.org/gallery/ima...85c6d956b5.jpg

                      Comment


                      • #12
                        Wow. Nice
                        Nothelle S2 Avant in restoration
                        Wr Ur Quattro (also in restoration)
